THE 2015 STATEWIDE REGIONAL EVACUATION STUDY UPDATE FOR THE
NORTH CENTRAL FLORIDA REGION
Volume 10-3: Storm Tide Directional Atlases

This Atlas is Volume 10 of the Statewide Regional Evacuation Study Program (SRESP), and one of four sets of county books in the North Central Florida Storm Tide Directional Atlas series. Book 1 covers Dixie County; Book 2 covers Taylor County; and Books 3 and 4 cover the two inland Counties which receive storm surge: Gilchrist and Lafayette. In each county, the primary volume presents an overview of the study and the methodology, while the Appendices, numbered from A to C, include the surge inundation maps for each of three directional storm clusters for Approaching, Exiting, and Paralleling Storms.
Book 1: Dixie County Storm Tide Directional Atlas
Directional
Atlas
Approaching Storms
(N-ENE)
Exiting Storms
(SW-WNW)
Paralleling Storms
(WNW-N)

Book 2: Taylor County Storm Tide Directional Atlas
Directional
Atlas
Approaching Storms
(N-ENE)
Exiting Storms
(SW-WNW)
Paralleling Storms
(WNW-N)

Book 3: Gilchrist County Storm Tide Directional Atlas
Directional
Atlas
Approaching Storms
(N-ENE)
Exiting Storms
(SW-WNW)
Paralleling Storms
(WNW-N)

Book 4: Lafayette County Storm Tide Directional Atlas
Directional
Atlas
Approaching Storms
(N-ENE)
Exiting Storms
(SW-WNW)
Paralleling Storms
(WNW-N)
